ELITE Key Management System - 120 / 132 keys


Brand
:
IKLAS
Supplier
:
EWINS SDN BHD
Email
:
ejyeoh@ewins.com.my
Phone
:
016-6786112
Location
:
Selangor, Malaysia



iKLAS ELITE

The Elite Series is our upgraded Electronic Key Management System that comes with a 7” industrial grade touchscreen and allows for a more user-friendly experience as information such as reports, and audit trails can be easily obtained.

The Elite Series also packs more features and functions which would cater to the ever-changing demands of every industry.

Key Features
• Built-in 7” Industrial Grade Color Touchscreen
• Built- in color camera for security and verification upon access
• Built- in SMS / Email alarm triggers and warnings (optional)
• Built in Auto Tag return Function
• Reader to support different access modes, including cards (Mifare, HID, CEPAS, SSID, Desfire EV1 & Desfire EV2),
user ID + PIN, or by fingerprint and other bio authentication (CEPAS & SSID are applicable only in Singapore)
• Up to 10 different RFID key tag (encrypted) colors for easy differentiation
• Embedded Key Management Software
• Live key status update
• Manual bypass in case of system breakdown
• Tamper proof key rings / seals with unique serial number
• Up to 5,000 users, 320 key groups, 64 time schedules, 20,000 transactions & 100,000 user photo images
• Embedded Linux OS, application software and database

• Web-based platform for system configuration, monitoring & management
• Centralised Management System (optional)
• Highly secured multiple user logins
• Real time key status update
• Remote configuration and monitoring of the system
• Fraud management with audit trail
• Report-generator for specific reports
• Automatic or predefined upload and download of information through network
Note: SDK/TCP/IP interface are available for integration



MODEL

ELITE iKLAS-R120/132

Input Voltage

110/240VAC

Maximum Input Current

16A/115Vac, 8A/230Vac

Frequency

50/60Hz

Back-Up Battery

12V/7Ah

Standby in battery mode

≤ 8Hrs

Operating in battery mode

≤120 Transactions

Operating Temperature

10◦c to 40◦c

Humidity

<95%

Size

(W) 680mm (H) 750mm (D) 230mm

Weight

50KG

Max. Number of Key Slots

132 key slots per cabinet (11 rows of 12)

Operating Systems

Linux

Interface

TCP/IP
